| Printing |
| Print Technology |
Fused Deposition Modeling |
| Build Volume |
160*160*200 mm |
| Number of Nozzles |
Single |
| Layer Resolution |
0.05 mm |
| Filament Diameter |
1.75 mm |
| Filament Compatibility |
PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PTEG, HIPS, PP, Flexible, TPU, PVA, PEEK, etc. |
| Nozzle Diameter |
0.4 mm（0.3 0.5 0.6 0.8 1.0 mm） |
| Print File Type |
STL, OBJ, AMF, Gcode |
| Electrical |
| Power Requirements |
techSpecs.electrical.powerRequirementsValue |
| Rated Power |
F160: 340W, F160 PEEK: 1100W |
| Screen |
4.3" Touch Screen with Multi-language |
| Storage Media |
U Disk |
| Connectivity |
USB |
| Mechanical |
| Construction |
Power-Coated Steel, Aluminum Casting for Motion Components, POM etc |
| Build Plate |
Heatable Aluminium PCB with BuildTak |
| Build Plate Leveling |
Manually |
| Extruder |
Directly Drive |
| Stepper Motors |
1.8°Step Angle with 1/16 Micro-stepping |
| X Y Positioning Precision |
12.7 μm |
| Z Positioning Precision |
1.25 μm |
| Speed |
| Best Printing speed |
70 mm/s |
| Max. Printing speed |
300 mm/s |
| Temperature |
| Ambient Operating Temperature |
15-32 ℃ |
| Max. Nozzle Temperature |
techSpecs.temperature.maxNozzleTemperatureValue |
| Max. Bed Temperature |
150 ℃ |
| Max. Chamber Temperature |
70 ℃ (F160-PEEK) |
| Software |
| Software |
CreatWare, Simplify 3D, Cura, Slic3r, etc |
| Supported File Types |
STL,OBJ,AMF |
| Operating Systems |
Win7/8/10, macOS |
| Special Function |
| Outage Restored |
Save data when power is off |
| Filament Detection |
Pause printing when filament run out |
| Automatic Shut-down |
Power off automatically when printing is complete |
| Size & Weight |
| Product Dimensions & Weight |
370*320*490 mm 18 kg |
| Packing Size & Weight |
470*420*600 mm 23 kg |
